DDL9000

Catenary voltage protection up to 3 kV

Protects your catenaries or the power supply rails for direct current electric traction.

Our DDL9000 protection relay facilitates the operation of your railway electrical networks thanks to its protection functions such as [di/dt] and its patented parallel line management version, or its high capacity for recording faults and events.

Its embedded web server and its touch screen HMI, allow you to calmly approach the future of your railway infrastructures.

#Catenary, #DC, #Protection, #Railway, #Relay

High resolution colour touch screen

Embedded web server

IEC 61850 ed2 or Modbus servers

Instantaneous tripping time in less than 30 ms

Sampling rate: 4 kHz

Operating temperature: -5 °C to 55 °C

Communication interfaces	1x RS485 - 1x cage SFP card RS485
Communication protocols	IEC 61850 ed2 IEC 61850-8-1 MMS IEC 618509-2 SV Modbus RTU Modbus TCP/IP
Mesures and operations	Catenary current — Catenary current monitoring Catenary voltage — Catenary voltage monitoring Perturbography — 400 Hz to 3,2 kHz (8 to 64 samples per period)
Mounting	Rack 19" - 3U
Power supply	48 to 125 Vdc
Type of option cards	1x RS485 - 1x cage SFP card
Current inputs	2
Voltage outputs	1
Disturbance records	32
Event logs	1000
Digital inputs	18
Digital outputs	12
Dedicated trip outputs	2
Watchdog output	1
Indication LEDs	16
Number of optional modules	1
